Electric Winch

• Model:87863
• Performance Voltage:DC 12V/24V
• Rated Line Pull(single line):17000 LB(7711 kg）
• Motor:6.8 Hp (5kw)Series Wound
• Gear train:3 Stage planetary
• Gear reduction Ratio:343:1
• Free Spooling Clutch:Up and Down
• Steel/Synthetic  Rope:12mm*24m
• Drum Diameter/Length:89mm*224m
• Braking action:Automatic in the drum
• Fairlead:4-way roller
• Duty Cycle:Intermittent
• Mounting bolt pattern:114mm*254mm
• Remote Control Cable:3 m
• Wireless Remote Control:Optional
• Dimensions：535*215*216 mm
• G.W./N.W.:56/54kg( 1 Pcs)
• Shipping Carton Size:60*40*29 cm(1 ctn)
